DOWSIL 3145 RTV Adhesive Sealant

Overview

DOWSIL 3145 RTV MIL-A-46146 Adhesive/Sealant is a one-part, moisture-cure, non-flowing silicone adhesive with high tensile strength and elongation, enhanced thermal stability, and MIL-A-46146 Group II/III, TY I compliance. It requires no mixing and cures at room temperature without ovens, with faster in-line processing available via optional heat acceleration. It is used for sealing openings in modules and housings, adding mechanical stability to individual components, assembly of components on printed wiring boards (PWBs), sealing in and around wired and electrical leads, and yoke assembly. Composition is a one-part polydimethylsiloxane adhesive, applied by automated or manual needle dispense.

Specifications

Color

Gray (also available Clear)

Strength

High

Base Type

RTV silicone (polydimethylsiloxane)

Cure Type

Alkoxy / methoxy cure (moisture-curing)

Service Temperature

-45°C to +200°C (thermal cycling to -55°C possible, performance-dependent)

Fixture Time

Tack-free 78 minutes at 25°C

Certifications

MIL-A-46146 Group II/III, TY I

Technical Information

• Tensile strength 1035 psi (7.1 MPa)
• Elongation 670%
• Durometer Shore A 51
• Tear strength (Die B) 190 ppi (132 N/cm)
• Primed adhesion 180° peel strength 106 ppi (72.5 N/cm)
• Extrusion rate 121 g/min
• Shelf life 12 months at 25°C

Typical Applications

• Sealing openings in modules and housings
• Adding mechanical stability to individual components
• Assembly of components on printed wiring boards (PWBs)
• Sealing in and around wired and electrical leads
