Devcon Plastic Steel Putty (A)

Overview

Devcon Plastic Steel Putty (A) is the original metal-filled epoxy putty used for hundreds of routine maintenance, production, and tooling applications. It patches and repairs areas where welding or brazing would be undesirable or impossible, bonds to most metals, concrete and some plastics, and cures at room temperature into a tough, durable metallic mass that can be drilled, tapped, machined or painted. Offers excellent resistance to oil, gasoline, water and many chemicals. Listed under NSN Stock #8030-00-903-6545 and #8030-00-962-4430.

Specifications

Color

Grey

Strength

High

Base Type

Epoxy, steel-filled

Cure Type

Room temperature cure; mix ratio 2.5:1 by volume

Service Temperature

Wet 120°F (49°C); Dry 250°F (121°C)

Fixture Time

Pot life 45 minutes at 75°F

Full Cure Time

Functional cure 16 hours

Certifications

Qualifies under MMM-A-1754, Accepted for use in U.S. meat and poultry plants

Technical Information

• Compressive strength 8,260 psi (57 MPa)
• Shore D hardness 85
• Adhesive tensile shear 2,800 psi (19.3 MPa)

Typical Applications

• Patching and rebuilding worn or damaged metal surfaces
• Repairing areas where welding or brazing is undesirable
• Duplicating or tracing masters; short-run dies and molds
